Measuring range: -22 ° + 270 ° C / Resolution: 1 ° C
Optical measurement: 6: 1 (at 60 cm distance the measurement area has a diameter of 10 cm)
Fixed emissivity - ° C / ° F - illuminated display
Spegniumento automatically after 10 sec. inactivity '
Operating temperature - 32 to 122 ° F, from 0 to 50 ° C
Operating Humidity - 80% maximum relative humidity RH
Dimensions: 94x51x20 mm /
Including batteries (2x1.5V AAA)
Weight: 76 gr.
Measurement range
ranges / resolution - -30 to 270 ° C - -22 to 518 ° F / 0.1 ° C -0.1 ° F
accuracy - 22 + 518 ° F / -30 ° C + 270 + (2.5% of reading + 4 ° C / 2 ° C)
S ettings emissivity - emissivity digitally adjustable from 0.10 to 1.0
Factor of distance - distance relationship object 6: 1
Notes on accuracy - the accuracy is guaranteed from 18 ° C to 28 ° C (64 ° F 82 ° C) with relative humidity less than 80%.
Emissivity and IR Measurement Theory:
The IR temometri measure the temperature of the surface of an object.
The optics
the unit receives the energy emitted, reflected and transmitted.
The electronics
the device translates the information into a temperature value which is then
displayed on the LCD.
The amount of IR energy emitted by an object is proportional to its temperature and to the
its ability to emit energy. This ability is known as emissivity and is
of the material object and its surface finish.
The field values of emissivity
ranging from 0.1 for a very reflective object to 1.00 for a surface finish
smooth black.
